FMS-2000M

LIT-12013580

BMS integration

Objects Analog inputs Read/Write Availability of analog input objects

FMS2M-Bx1x FMS2M-Bx2x FMS2M-Bx3x FMS2M-Bx4x

AI-1 Analog input 1, differential pressure Read only Yes Yes Yes Yes

AI-2 Analog input 2, differential pressure No Yes Yes Yes

AI-3 Analog input 3, differential pressure No No Yes Yes

AI-4 Analog input 4, differential pressure No No No Yes

Table 5: Analog inputs for integration in a BMS

Note: In the following tables, the abbreviation NV refers to network variable.

Table 6: Binary inputs for integration in a BMS

Objects Binary inputs Read/Write Availability of binary input objects

FMS2M-Bx1x FMS2M-Bx2x FMS2M-Bx3x FMS2M-Bx4x

BI-1 Digital input 1, door switch 1 Read only Yes Yes Yes Yes

BI-2 Digital input 2, door switch 2 No Yes Yes Yes

BI-3 Digital input 3, door switch 3 No No Yes Yes

BI-4 Digital input 4, door switch 4 No No No Yes

Table 7: Analog values for integration in a BMS

Objects Analog values Read/

Write

Availability of analog value objects

FMS2M-Bx1x FMS2M-Bx2x FMS2M-Bx3x FMS2M-Bx4x

AV-1 Network Variable Temperature 1 Read or

write

Yes Yes Yes Yes

AV-2 Differential Pressure low alarm setpoint 1 Yes Yes Yes Yes

AV-3 Differential Pressure low warning setpoint 1 Yes Yes Yes Yes

AV-4 Differential Pressure high warning setpoint 1 Yes Yes Yes Yes

AV-5 Differential Pressure high alarm setpoint 1 Yes Yes Yes Yes

AV-6 Network Variable Humidity 1 Yes Yes Yes Yes

AV-7 Network Variable Temperature 2 No Yes Yes Yes

AV-8 Differential Pressure low alarm setpoint 2 No Yes Yes Yes

AV-9 Differential Pressure low warning setpoint 2 No Yes Yes Yes

AV-10 Differential Pressure high warning setpoint 2 No Yes Yes Yes

AV-11 Differential Pressure high alarm setpoint 2 No Yes Yes Yes

AV-12 Network Variable Humidity 2 No Yes Yes Yes

AV-13 Network Variable Temperature 3 No No Yes Yes

AV-14 Differential Pressure low alarm setpoint 3 No No Yes Yes

AV-15 Differential Pressure low warning setpoint 3 No No Yes Yes

AV-16 Differential Pressure high warning setpoint 3 No No Yes Yes

AV-17 Differential Pressure high alarm setpoint 3 No No Yes Yes

AV-18 Network Variable Humidity 3 No No Yes Yes

AV-19 Network Variable Temperature 4 No No No Yes

AV-20 Differential Pressure low alarm setpoint 4 No No No Yes

AV-21 Differential Pressure low warning setpoint 4 No No No Yes

AV-22 Differential Pressure high warning setpoint 4 No No No Yes

AV-23 Differential Pressure high alarm setpoint 4 No No No Yes

AV-24 Network Variable Humidity 4 No No No Yes
