FMS-2000M
LIT-12013580
21
Sensors
You can conduct a zero calibration and set alarm limits for each pressure sensor. On the zero calibration menu, you can create the zero
Zero calibration
However, due to imperfections in the sealing of the remote sensor enclosure and due to pressure accumulation in the wall, the pressure
Creating a zero oset
1. Leave the door open to equalize the pressure between the monitored space and the reference space.
2. On the home screen, tap the Settings icon to enter the settings menu.
3. To view analog input settings, tap Analog I/O.
4. On the analog screen, tap the Zero Calibration arrow.
5. On the zero callibration screen, tap the Create Zero Oset arrow.
6. Follow the instructions on screen and wait for the real-time view reading on the screen to stabilize for at least 10 seconds.
7. Proceed.
Resetting the zero oset
you repeat Creating a zero offset.
1. On the home screen, tap the Settings icon to enter the Settings menu.
2. To view analog input settings, tap Analog I/O.
3. On the analog screen, tap the Zero Calibration arrow.
4. On the zero callibration screen, tap Reset Zero Oset.
5. Proceed.
6. Checkmark icon.
Setting up alarms for each pressure sensor
1. On the home screen, tap the Settings icon.
2. On the Settings screen, tap Sensors.
3. On the Sensors screen, tap the Alarms arrow.
4. On the Alarm screen, switch Alarm Enabled on.
5. For each alarm limit, tap the arrow.
6. Enter the alarm limit and tap the Checkmark
To Next Page
