6.1.2. ›xetouch‹ software
The following explanations will help you understand the ›xetouch‹ software.
Designation Meaning
Operating
device
DALI operating device
Group (G) The ›xetouch‹ software communicates with the operating devices (max. 64 per DALI line) via
groups (max. 16).
A group can be switched and dimmed individually. Groups can also include EM, HID, LV, INC,
CONF, LED or Somfy operating devices.
Zone (Z) Zones are only used in the Colour Application. One zone consists of four predefined groups
representing the colours red, green, blue and white.
Scene (S) A scene is used to save a lighting situation defined by the setting of one or several groups.
Sequence
(SQ)
Several scenes are saved in a time-specific order in a sequence.
Schedule
(SDL)
One or several sequences and/or scenes are saved in a time-specific order in a schedule. A
schedule starts automatically every 24 hours at a preset time of the day.
Schedule list
(SDLL)
Each schedule is assigned to one weekday. In this way, a schedule list is created for the
calendar-controlled, uninterruptible automation of lighting situations.
Scheduler When Scheduler is activated, it appears in the Home menu and enables a sequence, schedule list
and schedule to be controlled manually (Start, Pause, Stop and Off).
Basic Application
Typical application examples for the Basic Application are rooms where mostly white light is used, e.g. public rooms,
production halls, restaurants and hotels.
You can define a maximum of
Colour Application
All colours of the RGB colour space are the result of the addition of the basic colours red, green and blue (RGB).
For a better representation of white light an additional white light source is used (RGBW colour mixing).
The colour control of a lighting system is performed in the Colour Application. The Colour Application is different
from the standard Basic Application with respect to the grouping of the operating devices.
16 groups with a total of 128 devices_
16 scenes_
99 sequences_
7 schedules_
1 schedule list_
