from the standard Basic Application with respect to the grouping of the operating devices.
In the ›xetouch‹ software, each RGB-/RGBW operating device is assigned to the colour scale (red, green, blue,
white) of a zone. Four zones with 4 colour scales are available. The colour scale of a zone corresponds to a group.
In the Home menu, the white light can be switched and dimmed via groups 1 to 4.
The table shows the assignment of the 16 groups to the four colours of the individual zones. Zone assignment is
automatically controlled by the software.
W R G B
Z1 1 5 6 7
Z2 2 8 9 10
Z3 3 11 12 13
Z4 4 14 15 16
Typical application examples for the Colour Application are rooms where mainly RGBW operating devices are used
to implement freely design colour changes and colour effects, e.g. in shop windows, bars and exhibition spaces.
You can define a maximum of
Plug Application
With the Plug Application only one zone is used with the groups 1-4. The groups represent the colours red, green,
blue and white. The assignment to a group is done via a connector on the operating device. The classification into
scenes is not possible.
...
4 zones with the 4 colours red, green, blue and white with a total of 128 devices_
16 scenes for white light_
8 colour scenes_
99 sequences_
7 schedules_
1 schedule list_
