2 Getting Started
22 Juno Series User Guide
Parts of the Juno series handheld
The following pages show the main parts of the handheld.
Figure 2.1 Juno series handheld – front view
Figure 2.2 Juno series handheld – left and right views
Soft keys
Inbox
OK
Microphone
Navigation and Enter keys
Start
Today
External GPS
antenna connector
Power button
Stylus holder
Reset button
Zoom
SIM card slot
(SC version)
MicroSD
card slot
Camera button
Lanyard tether point
Power LED
Camera lens
