Triple E CLASS C - 4.3 Cab Door; 4.4 Drivers;Passengers Power Seat Controls (Optional)

4-4
4.3 CAB DOOR
1. Power Door Lock:
This rocker switch controls the driver's and
passenger's side cab door locks. Depress one
side to lock and the other side to unlock.
2 Power Window:
This rocker switch controls the door window.
Depress the front side of the switch to open and
back side to close.
CLASS C & B
+
MOTORHOME
DRIVERS DOOR
SEAT CONTROLS (TYPICAL)
4.4 DRIVERS/PASSENGERS
POWER SEAT CONTROLS
(OPTIONAL)
1. Front Of Seat Height:
This spring loaded to centre switch sets the
height of the front of seat. Depress the
upper portion and hold the switch to raise
the front of the seat. Depress the lower
portion and hold to lower the front of the
seat.
2. Forward-Back Position:
This spring loaded to centre switch sets the
position of the drivers seat. Push the switch
forward and hold to move the seat forward.
Push the switch rearward and hold to move
the seat back. Pull the switch up to raise
the seat and down to lower.
3. Back Of Seat Height:
This spring loaded to centre switch sets the
height of the back of the seat. Depress the
upper portion and hold to raise the rear of
the seat. Depress the lower portion and
hold to lower the back of the seat.
4. Back Rest Angle:
This spring loaded lever controls the lock on
the back rest angle position mechanism.
Pull the lever up and hold to release
the position lock. Gently lean back to push
the back rest down. Lean forward to allow
the back rest to tilt up. Release the lever to
engage the lock and hold the back rest in
position.
