13-7
CLASS C & B
+
MOTORHOME
Dinette
Bed
DINETTE/BED
13.11 SEATS
To move the chairs forward or backward, use the
lever located on the front of the chair beneath the
skirt.
To swivel the chairs, pull on the lever located under
the frame on the right hand side.
CAUTION
These chairs are not equipped
with seatbelts and are not
approved for use while travelling.
CHAIRS (TYPICAL)
13.10 SLEEPING FACILITIES
1. Bedroom:
Standard sleeping facilities with a bed are
located at the rear of the coach.
2. Dinette:
The dinette also can be converted into a bed:
a. Remove cushions.
b. Lift table and remove the table legs.
c. Drop table between seats so that the edge
of the table rests on seat edge supports.
d. Arrange cushions to form a bed, placing
larger cushions in the center.
e. To convert back to a dinette, reverse the
above instructions.
Do not use sleeping facilities while motorhome is
in motion.
WARNING
