CLASS B
+
& C MOTORHOME
28
4.3 DRIVER'S/PASSENGER'S POWER SEAT CONTROLS
1. Front Of Seat Height:
This spring loaded to centre switch sets the height of the front of seat. Depress the upper portion and hold the
switch to raise the front of the seat. Depress the lower portion and hold to lower the front of the seat.
2. Forward-Back Position:
This spring loaded to centre switch sets the position of the drivers seat. Push the switch forward and hold to move the
seat forward. Push the switch rearward and hold to move the seat back. Pull the switch up to raise the seat and down
to lower.
3. Back Of Seat Height:
This spring loaded to centre switch sets the height of the back of the seat. Depress the upper portion and hold to raise
the rear of the seat. Depress the lower portion and hold to lower the back of the seat.
4. Back Rest Angle:
This spring loaded lever controls the lock on the back rest angle position mechanism. Pull the lever up and hold to
release the position lock. Gently lean back to push the back rest down. Lean forward to allow the back rest to tilt up.
Release the lever to engage the lock and hold the back rest in position
4.4 SEAT/SHOULDER BELTS
The driver and passenger seats are equipped with lap/shoulder belts. Every occupant must be seated in an approved seat
with the belt fastened whenever the motorhome is moving. Accident statistics prove the importance of the need to use
seat belts. Vehicle occupants not seated in an approved seat and restrained with a seat belt received more injuries of a more
serious nature than those properly restrained.
SEAT CONTROLS (TYPICAL)
1
2
3
4
LAP/SHOULDER BELT
