12.2.7 HOLDING TANK LEVEL INDICATORS
The holding tank levels may be checked on the monitor panel. Press the corresponding switch to check the level in each tank.
12.3 PLUMBING SYSTEM OPERATION
12.3.1 WATER HEATER
The motorhome is equipped with a 6 gallon water heater. The water may be heated in one of three ways:
1. With an LP gas burner.
2. With a 120-volt heating element (optional)
3. With an automotive engine heater while driving. (optional)
1. LP Gas Operation:
a. To ignite the heater, set the waterheater switch located on the monitor panel.
2. Operating Features:
a. The water heater is equipped with a preset water temperature control. The burner will bring the water temperature
up to the desired level and then automatically shut o.
b. It is also equipped with a temperature cut-o device in case the water temperature exceeds the preset limit. The
breaker will trip and shut down the burner. Before the burner will restart, the breaker will have to be reset. If it
continues to trip, have the unit checked and serviced. Refer to manufacturers operating instructions included in
the information package.
IMPORTANT
Be sure there is water in the hot water tank to prevent burning out the heating element when the power is turned on.
TANK LEVEL INDICATORS
