26
15 16
14
Ref. Description Part No.
- Heater can wire set (not shown) 83312730
- Triac and wires (not shown) P19520903
- Thermister (not shown) 22012030
14. Front cover pcb 7073708
15. Safeguard T100 Care front cover assembly S19520601
(includes pcb and start/stop switch)
16 . Safeguard Front cover assembly S19520602
(includes pcb and start/stop switch)
SPARE PARTS
