3
Introduction
This book contains all the necessary fitting and
operating instructions for your Triton Safeguard
and Safeguard T100 Care electric shower.
Take time to read this book thoroughly and
familiarise yourself with all instructions before
commencing installation. Please keep it for future
reference.
The shower installation must be carried out by a
suitably qualified person and in the sequence of
this instruction book.
Care taken during the installation will provide a
long, trouble-free life from your shower.
Specifications
Electrical
Nominal power Nominal power
rating at 240V rating at 230V
8.5kW – (40A MCB rating) 7.8kW – (40A MCB rating)
Water
Inlet connection – 15 mm diameter.
Outlet connection – ½” BSP male thread.
Entry Points
Water – bottom, back and top.
Cable – bottom, back and top.
Materials
Backplate, cover, controls, showerhead – ABS.
Sprayplate – Acetal.
Elements – Minerally insulated corrosion resistant
metal sheathing.
Dimensions
Height − 300 mm
Width − 208 mm
Depth − 95 mm
Standards and Approvals
Splashproof rating IPX4.
Complies with the requirements of current British
and European safety standards for household and
similar electrical appliances.
Complies with requirements of the British
Electrotechnical Approvals Board (BEAB).
Meets with Compliance with European
Community Directives (CE).
The following points will help you understand
how the shower operates:
a) Temperature/flow rate
The temperature control can be adjusted to provide
shower temperatures between 35°C and 47°C.
Alternatively, adjusting a temperature stop
mechanism inside the unit to 38°C, 41°C or 43°C
maximum can restrict the shower temperature.
IMPORTANT: To comply with BEAB CARE
MARK requirements (use in healthcare or
special needs environment) the Safeguard
T100 Care unit is factory set at 41°C (see
page 13) on how to adjust the MAXIMUM
temperature stop.
At a selected showering temperature the unit
will provide the optimum flow rate possible.
Note the maximum flow rate for the given
temperature will be greater in the summer
than in the winter because of the variance in
the ambient mains water supply.
Should water pressure/flow to the shower be
insufficient for optimum performance then
the unit will operate at a reduced power level
and provide the highest flow rate possible for
the given shower temperature.
b) Temperature stabilisation
The shower will deliver an outlet
temperature to within 1°C of the selected
setting. The shower will maintain temperature
in accordance with the BEAB CARE MARK.
If ever the water becomes too hot, and you
cannot obtain cooler water, first check that
the sprayplate in the showerhead has not
become blocked.
DO NOT place items such as soap or shampoo
bottles on top of the unit. Liquid could seep
through the joint between the cover and backplate,
and possibly damage the sealing rubber.
Y-003-A
Replacement parts can be ordered from Customer
Service. See ‘spare parts’ for details and part numbers.
IMPORTANT: When first installed the unit
will be empty. It is essential the unit should
contain water before the elements are
switched on. It is vital that the commissioning
procedure is followed. Failure to carry out this
operation will result in damage to the unit
and will invalidate the guarantee.
Advice to Users
