Speedy 360 flexx – Technical Specifications
32 20 in (813 508 mm)
35 23.6 in (890 600 mm)
Max. height of work piece
1.5 ", 2.0 ": 8.2 in (210 mm) incl. working table / 11 in (280 mm) without
working table
2.0 " clearance lens, 2.5": 7.7 in (197,5 mm)
2.85 " flexx lens: 7.4 in (188 mm)
3.2 ": 7 in (179 mm)
4.0 ": 6.2 in (159 mm)
5.0 ": 5.2 in (133 mm)
Multifunctional table concept including aluminum cutting grid table,
Rulers in inch or mm
Electronic, programmable Z-axis with servo motor
139 in/sec (355 cm/sec.) CO
2
78 in/sec (200 cm/sec.) fiber
Increment measuring system
Standard: 2.85 " flexx lens
Optional CO
2
: 1.5 ", 2.0 ", 2.0 " clearance lens – 0.5 in (12,5 mm) more
distance from the material than standard lenses, 2.5 ", 4.0 "
Optional fiber: 3.2", 5.0"
Accuracy to size of parts
Depending on material and process
Static: up to 220 lbs. (100kg) / Dynamic: up to 66 lbs. (30 kg)
Surface exhaust via rear of the engraving cabinet, table exhaust with
vacuum and cutting table
Sonar TechnologyTM, ergonomic access to working area, coaxial air assist
incl. integrated pump, InPack TechnologyTM, harsh environement protection
kit, multifunctional table concept incl. aluminum cutting grid table (black),
laser pointer (655 nm, <0,99mWcw), 2.85" flexx lens, nozzles (Ø3 mm und
Ø7 mm), LED light, housing with lockable casters, incl. water-chiller (if
requested), 2 years warranty or 3 years extended warranty in combination
with TroCare
USB connection, JobControl® Expert Software, UniDrive, iOS App
Rotary attachment, gas-kit light, temperature sensor incl. emergency stop
button, ferromagnetic engraving table, vacuum table, acrylic cutting grid
table (white), aluminum slat cutting table, acrylic slat cutting table,
honeycomb cutting table top with 0.5 in (12.7 mm) or 0.25 in (6,4 mm)
nominal comb size
