CHAPTER 2: ASSEMBLY INSTRUCTIONS
BIKE ASSEMBLY STEPS (continued):
Step 6: Mast Boot
) Pull down the Mast Boot
b) Attach the Mast Boot to the plastic shrouds
by tightening both screws with a Phillips head
screwdriver (not provided).
Hardware Required:
Step 7: Handlebar Cable Routing:
While at least one person holds the
H
andlebar, another person should direct the
Handlebar Cables through the Front Mast.
a) Insert the Handlebar U-bracket onto the
Front Mast. DO NOT PINCH CABLES.
b) For each screw, install through split washer
then
flat washer
c
) S
ecure the Handlebar to the Front Mast by
tightening all 3 screws with the provided hex
wrench
Hardware Required:
3 M
8 Spring Washers
Truefitness.com / 800.426.6570 / 636.272.7100 14
