CHAPTER 2: ASSEMBLY INSTRUCTIONS
BIKE ASSEMBLY STEPS (continued):
Step 10B: Cable Connections (console):
*Follow Step 10B if installing a 9” TFT console or an LED console. For other consoles, return to Step 10A.
Connect Data Cable (50-pin)
Both 9” TFT & Orange LED Consoles
Connect Power Cable (2-pin)
9” TFT Console Orange LED Console
NOTE: Ethernet & Coaxial cable connections are not available on the Orange LED or 9” TFT Consoles
All Ground Wires Must be connected
Truefitness.com / 800.426.6570 / 636.272.7100 18
