CHAPTER 2: ASSEMBLY INSTRUCTIONS
BIKE ASSEMBLY STEPS (continued):
Auxiliary Power Supply Installation Step C (remove wire tie):
Remove the wire-tie shown in the provided
This will release the Power Supply Input Plug
*Use caution not to drop the loose wire-tie into
the machine after it has been removed
Auxiliary Power Supply Installation Step D (input plug connection):
Connect the Input Plug to the Power Supply
NOTE: If necessary, the Mast Boot (installation
step # 6) can be removed to allow more access
to the Power Supply cable connections
Auxiliary Power Supply Installation Step D (output plug connection):
Raise Mast Boot (Optional)
Truefitness.com / 800.426.6570 / 636.272.7100 23
