CHAPTER 2: ASSEMBLY GUIDE
Truetness.com / 800.426.6570 / 636.272.7100
10
TREADMILL ASSEMBLY STEPS:
STEP 1 Remove Motor Cover:
a) Remove the 9 screws securing the mo-
tor cover to the treadmill frame.
b) Remove the motor cover and set to the
side.
STEP 2 Install Pedestal Uprights:
a) Slide the le and right pedestal uprights
into place.
*DO NOT PINCH CABLES
b) Install 4 bolts and washers into each
pedestal, but do not fully tighten.
