CHAPTER 2: ASSEMBLY GUIDE
Truetness.com / 800.426.6570 / 636.272.7100
12
TREADMILL ASSEMBLY STEPS CONTINUED:
STEP 5 Data Cable & Cable Cover:
a) Connect the lower control wire coming
out of le upright with the upper control
wire attached in the console.
b) Install the wire cover with 2 bolts to the
upper console cover.
STEP 6 Secure Pedestal Uprights:
a) Fully tighten the 8 bolts from Step 2.
b) Tighten the hex head bolt on the front
of each pedestal upright and then tighten
the nut.
