TSC Alpha-40L RFID User Manual

44
RFID
RFID Chip
Param
It is used to configure the system when support of custom RFID tags is required.
USR Size
This menu item selects the size in bytes of the USR block within the RFID tag memory.
Normally, this value is set automatically by the RFID calibration process and should not be
changed.
Minimum
0 (Default)
Maximum
256
Note: This value will be hidden if Higgs3 tags are detected, and the Higgs 3 USR Len menu will be
unhidden instead.
TID Size
This menu item indicates the size of the memory block within the RFID tag memory that contains
the Tag ID. Normally, this value is set automatically by the RFID calibration process and should
not be changed.
Minimum
0
Maximum
12
Default
8
Higgs 3
USR Len
Higgs 3 tags differ from other RFID tags in that its memory bank size is not fixed. To
accommodate EPC lengths longer than 96 bits, Higgs 3 borrows memory from the USR bank.
This display only menu indicates the size in bits of the USR block within the RFID tag memory.
Minimum
128
Maximum
512 (Default)
Note:
This menu will only be shown if a Higgs 3 tag is detected. Otherwise, it will be hidden.
Higgs 3
EPC Len
Higgs 3 tags differ from other RFID tags in that its memory bank size is not fixed. To
accommodate EPC lengths longer than 96 bits, Higgs 3 borrows memory from the USR bank.
This menu item selects the number of bits dedicated to the EPC block within the RFID tag
memory.
Minimum
96
Maximum
480
Default
96
Note:
This menu will only be shown if a Higgs 3 tag is detected. Otherwise, it will be hidden.
TAG
Length
This menu item selects the number of bytes in the EPC block within the RFID tag memory.
Normally, this value is set automatically by the RFID calibration process and should not be
changed.
Minimum
8
Maximum
64
Default
12
Note:
This value will be hidden if Higgs3 tags are detected, and the Higgs 3 EPC Len menu will be
unhidden instead.
