TSC DA220 Series User Manual

- 5 -
Max. print length
2,794 mm (110”) for DA210
1,016 mm (40”) for DA310
25,400 mm (1000”) for DA220
11,430 mm (450”) for DA320
Printout bias
Vertical: max. 1 mm
Horizontal: max. 1 mm
1.5 Media Specifications
Media Specifications
Media roll capacity
127 mm (5") OD
Media core diameter
1" (1.5") ID core
Note : 1.5’’ adapter (option)
Media type
Continuous, die-cut, black mark, External fan-fold, receipt
Media wound type
Outside wound
Media width
19 mm ~ 114 mm (0.7”~ 4.5”)
Media thickness
0.055 mm ~ 0.19 mm (2.16 ~ 7.48 mil)
Label length
10 ~ 2,794 mm (0.39” ~ 110”) for DA210
10 ~ 1,016 mm (0.39” ~ 40”) for DA310
10 ~ 25,400 mm (0.39” ~ 1000”) for DA220
10 ~ 11,430 mm (0.39” ~ 450”) for DA320
1” ~ 6” for peeler mode
1” ~ max. for cutter mode
Gap height
Min. 2 mm
Black mark height
Min. 2 mm
Black mark width
Min. 16 mm

TSC DA220 Series Specifications

General

Resolution	203 dpi / 300 dpi
Print Speed	Up to 152.4 mm (6”) per second
Print Width	54 mm (2.12”)
Memory	8 MB SDRAM
Processor	32-bit RISC
Interface	USB
Operating Temperature	-40°C to 60°C
Storage Temperature	-40 ~ 60°C (-40 ~ 140°F)
Power Supply	100-240V AC, 50/60 Hz
