TSC DA220 Series User Manual

- 7 -
2.2 Printer Overview
2.2.1 Front & rear
1. Top cover open lever
2. LED indicators
3. Feed/Pause button
4. External label entrance chute
5. Power switch
6. Power jack socket
7. USB interface
8. USB host (For DA220 series)
9. RS-232 interface (For DA220 series)
10. Ethernet interface (For DA220 series)
Note:
The interface picture in here is for reference only. Please refer to the product
specification for the interfaces availability.
6
5
4
P
o
w
e
r
L
E
D
in
di
c
a
t
o
r
7
8
9
10
2
3
P
o
w
e
r
L
E
D
in
di
c
a
t
o
r
1

TSC DA220 Series Specifications

General

Resolution	203 dpi / 300 dpi
Print Speed	Up to 152.4 mm (6”) per second
Print Width	54 mm (2.12”)
Memory	8 MB SDRAM
Processor	32-bit RISC
Interface	USB
Operating Temperature	-40°C to 60°C
Storage Temperature	-40 ~ 60°C (-40 ~ 140°F)
Power Supply	100-240V AC, 50/60 Hz
