TSC DA220 Series User Manual

- 13 -
3.2.2 Loading External Media
1. Open the printer top cover by pressing up the
top cover open tabs located on each side of
the printer.
2. Separate the media holders to the label
width.
3. Press down the media holder lock switch to
fix the media holder.

TSC DA220 Series Specifications

General

Resolution	203 dpi / 300 dpi
Print Speed	Up to 152.4 mm (6”) per second
Print Width	54 mm (2.12”)
Memory	8 MB SDRAM
Processor	32-bit RISC
Interface	USB
Operating Temperature	-40°C to 60°C
Storage Temperature	-40 ~ 60°C (-40 ~ 140°F)
Power Supply	100-240V AC, 50/60 Hz
