TSC DA220 Series User Manual

- 9 -
2.3 LED and Button Function
This printer has one button and one three-color LED indicator. By indicating the LED with different color
and pressing the button, printer can feed labels, pause the printing job, select and calibrate the media
sensor, print printer self-test report, reset printer to defaults (initialization). Please refer to the button
operation below and “Power-on Utilities” section for different functions.
2.3.1 LED Indication
LED Color
Description
Green/ Solid
This illuminates that the power is on and the device is ready to
use.
Green/ Flash
This illuminates that the system is downloading data from PC
to memory or the printer is paused.
Amber
This illuminates that the system is clearing data from printer.
Red / Solid
This illuminates printer head open, cutter error.
Red / Flash
This illuminates a printing error, such as head open, paper
empty, paper jam, or memory error etc.
2.3.2 Regular Button Function
1. Feed labels
When the printer is at ready states (Green/ Solid), press the button to feed one label to the beginning of next.
2. Pause the printing job
When the printer is at printing states, press the button to pause a print job. When the printer is paused the
LED will be green blinking. Press the button again to continue the printing job.

TSC DA220 Series Specifications

General

Resolution	203 dpi / 300 dpi
Print Speed	Up to 152.4 mm (6”) per second
Print Width	54 mm (2.12”)
Memory	8 MB SDRAM
Processor	32-bit RISC
Interface	USB
Operating Temperature	-40°C to 60°C
Storage Temperature	-40 ~ 60°C (-40 ~ 140°F)
Power Supply	100-240V AC, 50/60 Hz
