TSC DA220 Series User Manual

- 15 -
3.2.3 Loading Media in Peel-off Mode (Option for DA220 series)
1. Please refer to section 3.2.1 to load the
media. Place the label leading edge onto the
platen roller.
2. Close the top cover gently. Use “Diagnostic
Tool” to set the media sensor type, calibrate
the selected sensor and set the post-print
action to “PEEL”.
Note:
Please calibrate the sensor before loading media
into the peel-off module for avoiding paper jam.
3. Open the top cover and peel-off cover. Feed
the media into peel-off cover slot.
4. Close the peel-off cover and printer cover.
Note:
Make sure the latches of peel-off cover are engaged securely by printer cover.

TSC DA220 Series Specifications

General

Resolution	203 dpi / 300 dpi
Print Speed	Up to 152.4 mm (6”) per second
Print Width	54 mm (2.12”)
Memory	8 MB SDRAM
Processor	32-bit RISC
Interface	USB
Operating Temperature	-40°C to 60°C
Storage Temperature	-40 ~ 60°C (-40 ~ 140°F)
Power Supply	100-240V AC, 50/60 Hz
