TSC MH341 Series User Manual

- 2 -
1.2 Product Specification and Features
STANDARD
Advanced
PREMIUM
Model
MH241
MH341
MH641
MH241T
MH341T
MH641T
MH241P
MH341P
MH641P
Resolution
8 dots/mm
(203 DPI)
12 dots/mm
(300 DPI)
24 dots/mm
(600 DPI)
8 dots/mm
(203 DPI)
12 dots/mm
(300 DPI)
24 dots/mm
(600 DPI)
8 dots/mm
(203 DPI)
12 dots/mm
(300 DPI)
24 dots/mm
(600 DPI)
Printing
method
Thermal transfer and direct thermal
Max. print
speed
356 mm
(14”)/second
305 mm
(12”)/secon
d
152 mm
(6”)/second
356 mm
(14”)/second
305 mm
(12”)/secon
d
152 mm
(6”)/second
356 mm
(14”)/second
305 mm
(12”)/second
152 mm
(6”)/second
Max. print
width
104 mm(4.09”)
Max. print
length
25,400 mm
(1000”)
11,430 mm
(450”)
2540 mm
(100”)
25,400 mm
(1000”)
11,430 mm
(450”)
2540 mm
(100”)
25,400 mm
(1000”)
11,430 mm
(450”)
2540 mm
(100”)
Enclosure
Die-cast print mechanism and base with bi-fold metal cover with large clear media view window
Physical
dimension
276 mm (W) x 326 mm (H) x 502 mm (D)
10.87” (W) x 12.83” (H) x 19.76” (D)
276 mm (W) x 412 mm (H) x 502 mm (D)
10.87” (W) x 16.22” (H) x 19.76” (D)
Weight
15.35kg (33.84 lbs)
15.43 kg (34.02 lbs)
18.93kg (41.73 lbs)
Label roll
capacity
203.2 mm (8”) O.D.
Internal
rewinder (full
roll)
Internal rewinding kit (5” O.D.) (dealer option)
Standard (8” O.D.)
Ribbon
600 m long, max. O.D. 90 mm, 1” core (ink coated outside or inside)
Ribbon width
25.4 mm ~ 114.3 mm (1” ~ 4.5”)
Processor
32-bit RISC CPU
Memory
 512MB Flash memory
 256MB DDR2
 microSD Flash memory card reader for Flash memory expansion, up to 32 GB
TPH feature
 Support TSC TPH Care and TPH odometer
Interface
 RS-232
 USB 2.0 (High speed mode)
 Internal Ethernet, 10/100 Mbps
 USB host *2 (Front side), for scanner or PC keyboard
 GPIO (DB15F) + Centronics (factory option)
 Internal Bluetooth 5.0 MFi (factory option)
 Slot-in 802.11 1/b/g/n/ac Wi-Fi + BT combo module kit (dealer option)
