TSC MH341 Series - Loading the Media

21
3.4 Loading the Media
3.4.1 Loading the Media
1. Open the printer right side cover.
2. Move the label roll guard horizontally to the end of label spindle, then flip down the label roll
guard. For 1” spindle model, it supports the media with 1” core.
For 1.5” spindle model
For 1” spindle model
Using media with 3” core:
Using media with 1” core:
Remove the 3” core adapters.
