TSC MH341 Series - Loading Media in Rewind Mode (Option for MH241 P Series)

27
3.4.4 Loading Media in Rewind Mode (Option for MH241P Series)
1. Open the printer right side cover.
2. Please refer to section 3.4.1 for loading
media.
3. Using the front display panel to do the
calibration and set the printer mode to
rewind mode.
4. Open the printer lower cover, then push
the label guide to the far right side and pull
it down.
PUSH
