TSC MH341 Series User Manual

33
Symptom
1. Wrinkle happens from label
lower left to upper right
direction (“ˊ”)
2. Wrinkle happens from label
lower right to upper left
direction (“ˋ”)
Wrinkle
Example
If the wrinkle on the label starts from
the lower left side to upper right side,
please do following adjustment.
1. Switch the ribbon tension
adjustment knob clockwise per 1
level and print the label again to
check if the wrinkle is gone.
2. If the ribbon tension adjustment
knob has positioned on the level of
innermost side but didn’t improve
the ribbon wrinkle, please switch
the print head pressure position
adjustment knob per 1 level and
print the label again to check if the
wrinkle is gone.
3. If the ribbon wrinkle still can’t
improve after switch the print head
pressure position adjustment knob,
please adjust the print head
pressure adjustment knob per 1
level again to check if the wrinkle is
gone.
If the wrinkle on the label starts from
the lower right side to upper left side,
please do following adjustment.
1. Switch the ribbon tension
adjustment knob
counterclockwise per 1 level
and print the label again to
check if the wrinkle is gone.
2. If the ribbon tension adjustment
knob has positioned on the
level of outermost side but
didn’t improve the ribbon
wrinkle, please switch the print
head pressure position
adjustment knob per 1 level
and print the label again to
check if the wrinkle is gone.
3. If the ribbon wrinkle still can’t
improve after switch the print
head pressure position
adjustment knob, please adjust
the print head pressure
adjustment knob per 1 level
again to check if the wrinkle is
gone.
Feed
direction
