TDP-225 Series
Bar Code Printer Service Manual
2
1.2 Interior View
1. Top cover
2. Media holder
3. Media guide
4. Printhead
5. Gap sensor (receiver)
6. Gap sensor (transmitter)
7. Platen roller
8. Black mark sensor
9. Media holder lock switch
7
6
5
4
1
8
3
2 (TDP-225 model)
2 (TDP-225W
model)
9
