TDP-225 Series
Bar Code Printer Service Manual
3
1.3 Rear View
TDP-225/324 model
TDP-225W/324W model
1. Power switch
2. Power jack socket
3. USB interface
4. RS-232C interface(Option for TDP-225W/324W mode)
5. Fan-fold paper entrance chute
6. Ethernet interface (Option for TDP-225/324 model)
1
4
3
2
5
6
1
3
2
