33
TTP
-
243
Pro/ 243E Pro/ 342 Pro
Bar Code Printer
Printer carriage releas
e lever arm and E ring
5.
Remove the teflon tube and stripper rod.
Teflon tub
e and stripper rod
6.
Remove the E ring, the right si
de and left side platen bushes.
7.
Remove the stripper bar.
Remove E ring and platen bush
Teflon T
ube
E Ring
Teflon T
ube
Printer
Carriage
Release Lev
er
A
r
m
Stripper
Bar
Platen Bush
(Right Side)
E Ring
Platen Bush
(Left Side)
35
