1.4 Basic Specifications
Thermal transfer and direct thermal printing
High dot density printing (243 Pro series: 203 dots/inch, 342 Pro series: 300 dots/inch)
Selectable print speeds at 1.5”, 2.0” or 3.0” per second (243 Pro series: 1.5, 2 and 3 ips /
342 Pro series: 1, 1.5 and 2 ips)
Supports RS-232 serial and USB interface (Factory option for RS-232 and Centronics
interface)
Maximum media width up to 4.49” (114 mm)
Adjustable label edge guide
International character sets
Print area：TTP-243 Pro/243E Pro：4.09” W x 90” L；TTP-342 Pro：4.09”W x 40”L (without any
file downloaded in the printer memory)
User selectable bar code ratios and heights
Prints on labels or tickets
Equipped with black mark sensor
Equipped with Real Time Clock (Not available for TTP-243E Pro)
Comes with self-peeling function (Not available for TTP-243E Pro)
Buzzer provided to warn of possible errors (Not available for TTP-243E Pro)
Label stock and thermal transfer ribbon are easy to install
Internal label print counter
Self test and hex dump mode
Downloadable fonts from label design software
Electronics/Communication Specifications
Electrical
DC Motor: DC24V
Memory:
─SDRAM: 8 Mb
─Flash: 4 Mb
Adapter 100~240VAC10%, 50~60Hz
Regulations: FCC Class A, CE Class A, C-Tick Class A, TÜ V/Safety, CCC
Communications Interface:
Serial port: RS-232C (DB-9) at 2400, 4800, 9600 or 19200 baud rate
─Word Length: 7 or 8 data bits, 1 or 2 stop bits, selectable parity
─Handshaking: XON/XOFF and DSR/DTR
Parallel port: Standard parallel interface
Input Buffer: 64KB
RS-232 Interface Pin Configuration:
