TSC TTP-247 Series User Manual

19
4. LED and Button Functions
4.1 LED Indicator
Color
Meaning
(Green)
Solid: Power is on and ready to be used.
Flash :System is downloading data or printer is paused.
(Amber)
System is clearing data.
(Red)
Solid - Printer head open, cutter error.
Flash - Printing error, such as paper empty, paper jam, ribbon empty, or memory error etc.
4.2 Regular Button Function
1. Feed labels
When the printer is ready, press the button to feed one label to the beginning of next label.
2. Pause the printing job
When the printer is printing, press the button to pause a printing job. When the printer is paused, the LED will be green blinking.
Press the button again to continue the printing job.

TSC TTP-247 Series Specifications

General

Resolution	203 dpi
Max Print Width	4.09" (104 mm)
Processor	32-bit RISC CPU
Operating Temperature	41°F to 104°F (5°C to 40°C)
Print Method	Thermal Transfer and Direct Thermal
Max Print Speed	7 ips
Memory	8 MB SDRAM
Interface	USB 2.0
Ribbon Capacity	300 meters
Media Sensor	Reflective, Transmissive
Label Width	1" (25.4 mm) ~ 4.33" (110 mm)
Label Thickness	0.0028" to 0.008" (0.07 mm to 0.2 mm)
Power Supply	100-240V AC, 50/60 Hz
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Operating Humidity	25 ~ 85% non-condensing
Maximum Print Length	39.37" (1000 mm)
