5.5 Printer Function

Printer Function could be found in Printer Configuration. “Printer Function” will be shown on the left side of the window.

Functions

Description

Calibrate Sensor

Detect media types and the size of the label

RTC Setup

Synchronize printer with Real Time Clock on PC

Factory Default

Initialize the printer to default settings

Reset Printer

Reboot printer

Print Test Page

Print test page according to the specified label size and sensor type.

Configuration Page

Print printer configurations

Dump Text

Activate the printer to dump mode

Ignore AUTO.BAS

Ignore AUTO.BAS file when printer boot up.

Exit Line Mode

Exit the line mode to page mode

Enter Line Mode

Leave page mode and enter line mode

Reset WiFi

Restore the WiFi settings to defaults.

Questions and Answers:

Need help?

Do you have a question about the TSC TTP-247 Series and is the answer not in the manual?

TSC TTP-247 Series Specifications

General

Resolution	203 dpi
Max Print Width	4.09" (104 mm)
Processor	32-bit RISC CPU
Operating Temperature	41°F to 104°F (5°C to 40°C)
Print Method	Thermal Transfer and Direct Thermal
Max Print Speed	7 ips
Memory	8 MB SDRAM
Interface	USB 2.0
Ribbon Capacity	300 meters
Media Sensor	Reflective, Transmissive
Label Width	1" (25.4 mm) ~ 4.33" (110 mm)
Label Thickness	0.0028" to 0.008" (0.07 mm to 0.2 mm)
Power Supply	100-240V AC, 50/60 Hz
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Operating Humidity	25 ~ 85% non-condensing
Maximum Print Length	39.37" (1000 mm)
