TSC TTP-247 Series User Manual

26
For WPA-Personal
I. Fill-in the SSID.
II. Select the Encryption option to WPA-Personal.
III. Fill-in the Key.
IV. Select DHCP to ON. (For OFF option, please fill-in the
IP Address, Subnet Mask and Gateway)
V. After setting, click the Set button.
Note:
Before setting, the entered field will be shown in yellow for
reminding.
On DHCP, user can change the printer name by another
model name in “Printer Name” field.
User also can change the raw port in “Raw Port” field.
For WPA-Enterprise
I. Fill-in the SSID.
II. Select the Encryption option to WPA2-Enterprise.
III. Select DHCP to ON (For OFF option, please fill-in the IP
Address, Subnet Mask and Gateway)
IV. Select the EAP Type option. (For EAP-TLS option,
please upload the CA and Key for mutual authentication,
integrity-protected cipher suite negotiation, and key
exchange between two endpoints.)
V. After setting, click the Set button.
Note:
Before setting, the entered field will be shown in yellow for
reminding.
On DHCP, user can change the printer name by another
model name in “Printer Name” field.
User also can change the raw port in “Raw Port” field.
1
2
3
2
1

TSC TTP-247 Series Specifications

General

Resolution	203 dpi
Max Print Width	4.09" (104 mm)
Processor	32-bit RISC CPU
Operating Temperature	41°F to 104°F (5°C to 40°C)
Print Method	Thermal Transfer and Direct Thermal
Max Print Speed	7 ips
Memory	8 MB SDRAM
Interface	USB 2.0
Ribbon Capacity	300 meters
Media Sensor	Reflective, Transmissive
Label Width	1" (25.4 mm) ~ 4.33" (110 mm)
Label Thickness	0.0028" to 0.008" (0.07 mm to 0.2 mm)
Power Supply	100-240V AC, 50/60 Hz
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Operating Humidity	25 ~ 85% non-condensing
Maximum Print Length	39.37" (1000 mm)
