TSC TTP-247 Series User Manual

33
Check if print density is set properly.
Adjust the print density and print speed.
Check print head test pattern if head element is
damaged.
Run printer self-test and check the print head test
pattern if there is dot missing in the pattern.

TSC TTP-247 Series Specifications

General

Resolution	203 dpi
Max Print Width	4.09" (104 mm)
Processor	32-bit RISC CPU
Operating Temperature	41°F to 104°F (5°C to 40°C)
Print Method	Thermal Transfer and Direct Thermal
Max Print Speed	7 ips
Memory	8 MB SDRAM
Interface	USB 2.0
Ribbon Capacity	300 meters
Media Sensor	Reflective, Transmissive
Label Width	1" (25.4 mm) ~ 4.33" (110 mm)
Label Thickness	0.0028" to 0.008" (0.07 mm to 0.2 mm)
Power Supply	100-240V AC, 50/60 Hz
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Operating Humidity	25 ~ 85% non-condensing
Maximum Print Length	39.37" (1000 mm)
