General| Resolution | 203 dpi |
|---|---|
| Max Print Width | 4.09" (104 mm) |
| Processor | 32-bit RISC CPU |
| Operating Temperature | 41°F to 104°F (5°C to 40°C) |
| Print Method | Thermal Transfer and Direct Thermal |
| Max Print Speed | 7 ips |
| Memory | 8 MB SDRAM |
| Interface | USB 2.0 |
| Ribbon Capacity | 300 meters |
| Media Sensor | Reflective, Transmissive |
| Label Width | 1" (25.4 mm) ~ 4.33" (110 mm) |
| Label Thickness | 0.0028" to 0.008" (0.07 mm to 0.2 mm) |
| Power Supply | 100-240V AC, 50/60 Hz |
| Storage Temperature | -4°F to 140°F (-20°C to 60°C) |
| Operating Humidity | 25 ~ 85% non-condensing |
| Maximum Print Length | 39.37" (1000 mm) |
