TSC TTP-247 Series User Manual

3
Dealer option
 Peel off module assembly
Support paper: Art paper (Plain paper)
Support label length: 1”~6”
Support speed: 2~3 ips
 Guillotine cutter
Full cut:
Media thickness: 0.06~ 0.19mm
Media type: receipt and label liner w/o glue
Partial cut:
Media thickness: 0.06~0.12mm
Media type: receipt and label liner w/o glue
Note: Except for the linerless cutter, all regular/heavy duty/care label cutters DO NOT cut on media with glue.
 Main board integrated with internal Ethernet
 Internal Ethernet print server module
User option
 KP-200
 KU-007 plus
 External Ethernet print server
 External wireless (802.11b/g) print server
 External roll mount, media OD. 214 mm (8.4”) with 3” core label spindle
 Contact CCD contact scanner
 Long range linear image bar code scanner

TSC TTP-247 Series Specifications

General

Resolution	203 dpi
Max Print Width	4.09" (104 mm)
Processor	32-bit RISC CPU
Operating Temperature	41°F to 104°F (5°C to 40°C)
Print Method	Thermal Transfer and Direct Thermal
Max Print Speed	7 ips
Memory	8 MB SDRAM
Interface	USB 2.0
Ribbon Capacity	300 meters
Media Sensor	Reflective, Transmissive
Label Width	1" (25.4 mm) ~ 4.33" (110 mm)
Label Thickness	0.0028" to 0.008" (0.07 mm to 0.2 mm)
Power Supply	100-240V AC, 50/60 Hz
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Operating Humidity	25 ~ 85% non-condensing
Maximum Print Length	39.37" (1000 mm)
