TSC TTP-2610MT Series User Manual

5
1.2 General Specification
General Specifications
Physical dimensions
355 mm (W) x 337 mm (H) x 520 mm (D)
Weight
21.5 kg
Power
Internal switching power supply
Input: AC 100-240V, 3.0A, 50-60Hz
Output: DC 24V, 8.33A, 200W
Environmental condition
Operation: 5 ~ 40˚C (41 ~ 104˚F), 20~85% non-condensing
Storage: -40 ~ 60 ˚C (-40 ~ 140˚F), 10~90% non-condensing
Environmental concern
Comply with RoHS, WEEE
1.3 Print Specification
Print Specifications
203 dpi
models
300 dpi
models
Print head resolution
(dots per inch/mm)
203 dots/inch
(8 dots/mm)
300 dots/inch
(12 dots/mm)
Printing method
Thermal transfer/ or direct thermal
Dot size
(width x length)
0.125 x 0.125 mm
(1 mm = 8 dots)
0.084 x 0.084 mm
(1 mm = 12 dots)
Print speed
(inches per second)
Up to 12 ips
(11~12 ips for special media)
Up to 10 ips
(9-10 ips for special media)
Max. print width
168 mm (6.61”)
168 mm (6.61”)
Max. print length
11,430 mm (450”)
5,080 mm (200”)
Printout bias
Vertical: 1 mm max.
Horizontal: 1 mm max.
