TSC TTP-2610MT Series - 3.6 Loading the Media in Peel-off Mode (Option)

22
3.6 Loading the Media in Peel-off Mode (Option)
1. Install the label and calibrate the selected sensor.
2. Install the paper core on internal rewind spindle.
3. Pulling the lower cover of print head up as picture
showed.
4. Place the label through the peel-off cover slot and
platen roller.
