TSC TTP-2610MT Series - 3.3 Loading the Media

17
3.3 Loading the Media
1. Lift the handle to open the printer right side cover.
Push the print head release lever to open the print
head mechanism.
2. Remove one label roll guard from the label spindle.
3. Place the roll of media on the label supply spindle
and push it to the end of label spindle. Install the
label roll guard gently to fit the width of label roll.
