23
5. Please note the direction of label (printing side facing
up).
6. Paste the media on the paper core and rolling it
counterclockwise for 3 to 5 circles until the liner is
completely stretched.
7. Pulling the lower cover down to close the print head
and test the function in peel-off mode
Note:
*Please calibrate the gap/black mark sensor when
changing media.
