TSC TTP-345 Service Manual

10
Dealer option
 Peel off module assembly.
 Guillotine cutter
Full cut:
Paper thickness: 0.06~ 0.19mm, 500,000 cuts
Partial cut:
Paper thickness: 0.06~0.12mm, 500,000 cuts
Paper thickness: 0.19mm 200,000 cuts
User option
 KP-200 Plus
 KU-007 Plus
 HCS-200 long range linear image bar code scanner
 Bluetooth module
1.2.3. LED
LED Color
Description
Green/ Solid
This illuminates that the power is on and the device is
ready to use.
Green/ Flash
This illuminates that the system is downloading data
from PC to memory and the printer is paused.
Amber
This illuminates that the system is clearing data from
printer.
Red / Solid
This illuminates printer head open, cutter error.
Red / Flash
This illuminates a printing error, such as paper empty,
paper jam, ribbon empty, or memory error etc.
1.2.4. Button
Feed
 Press the button when the LED is green.
 It feeds the label to the beginning of the next label.
Pause
 Press the feed button during printing
 The printing job is suspended.

TSC TTP-345 Specifications

General

Print Method	Thermal Transfer
Resolution	300 dpi
Max Print Speed	5 ips
Max Print Length	90" (2286 mm)
Memory	8 MB Flash
Interface	USB 2.0, RS-232
Power Supply	External universal switching power supply
