TSC TTP-345 Service Manual

12
Printer Initialization
1. Turn off the power switch.
2. Hold on the button then turn on the power switch.
3. Release the button when LED turns green after 5 amber
blinks. (Any green will do during the 5 blinks).
 The LED color will be changed as following:
Amber  red (5 blinks)  amber (5 blinks) 
green (5 blinks)  green/amber (5 blinks) 
red/amber (5 blinks)  solid green
Note:
Always do gap/black mark sensor calibration after
printer initialization.
Force Black Mark
Sensor Calibration
1. Turn off the power switch.
2. Hold on the button then turn on the power switch.
3. Release the button when LED turns green/amber after 5
green blinks. (Any green/amber will do during the 5
blinks).
 The LED color will be changed as following:
Amber  red (5 blinks)  amber (5 blinks) 
green (5 blinks)  green/amber (5 blinks) 
red/amber (5 blinks)  solid green
Force Gap Sensor
Calibration
1. Turn off the power switch.
2. Hold on the button then turn on the power switch.
3. Release the button when LED turns red/amber after 5
green/amber blinks. (Any red/amber will do during the 5
blinks).
 The LED color will be changed as following:
Amber  red (5 blinks)  amber (5 blinks) 
green (5 blinks)  green/amber (5 blinks) 
red/amber (5 blinks)  solid green

TSC TTP-345 Specifications

General

Print Method	Thermal Transfer
Resolution	300 dpi
Max Print Speed	5 ips
Max Print Length	90" (2286 mm)
Memory	8 MB Flash
Interface	USB 2.0, RS-232
Power Supply	External universal switching power supply
