TTP-2410M/346M/644M
TTP-246M Plus/344M Plus
Bar Code Printe
r
Service Manual
3. MECHANISM
3.1 Remove Covers and the Lower Front Panel
1. Remove two screws from rear of printer.
2. Open printer right side cover and remove two screws then close the cover.
3. Push the printer left side electronics cover toward the interface direction then take it out
from the printer. Please refer to the following pictures.
Screws
Screws
