TTP-2410M/346M/644M
TTP-246M Plus/344M Plus
Bar Code Printe
r
Service Manual
3.10 Replacing the Media Damper
1. Open the printer right side cover.
2. Remove the screw that fixes the damper to the mechanism.
3. Remove/Replace the media damper.
4. Reassemble the parts in the reverse procedures.
Screw
Media damper
