TSC TTP-346M User Manual

2
TTP-2410M/346M/644M
TTP-246M Plus/344M Plus
Bar Code Printe
r
Service Manual
Interior View
1. Ribbon rewind spindle
2. Ribbon release button
3. Ribbon guide plate
4. Print head
5. Platen roller
6. Print head release lever
7. Media guide bar
8. Label roll guard
9. Label supply spindle
10. Ribbon supply spindle
11. Damper
12. Label guide
13. Z axis mechanism adjustment knob
14. Print head pressure adjustment knob
15. Print head secure screw
16. Ribbon sensor
17. Media sensor
5
8
7
9
6
10
4
12
3
1
2
13
11
14
15
17
16

TSC TTP-346M Specifications

General

Brand	TSC
Model	TTP-346M
Category	Barcode Reader
Language	English
