Instrument Operation 4-13
C a u t i o n
Remove the flash memory card following the correct procedures:
1. Use Safely Remove Hardware option in Windows to disconnect the
card reader from the computer—stop USB Mass Storage Device.
2. After the message Safe To Remove Hardware: The “USB Mass
Storage Device” device can now be safely removed from the system
appears, physically remove the flash memory card from the card
reader.
Failure to follow these procedures may result in failure to log data with
the flash memory card.
Aerosol I n s trume n t M a nager
®
Sof t w a r e
Aerosol Instrument Manager
®
software is supplied with the 3772/3771
CPCs. This program provides many useful data acquisition, display,
processing, and download functions used in particle measurements.
Review the supplied Aerosol Instrument Manager
®
software manual for
complete information on software functions.
Moving and S h i p p i ng t he C P C
Make sure the Model 3772/3771 CPC is turned off and remains upright
while moving the instrument. There is no need to drain the CPC before
moving it. Prior to shipping, however, it is necessary to drain butanol from
the instrument. Refer to “Draining Butanol from the Butanol Reservoir” in
Chapter 8 to drain the CPC.
TSI recommends that you keep the original packaging (carton and foam
inserts) of the CPC for use whenever the CPC is shipped, including when it
is returned to TSI for service. Always seal off the sampling inlet to prevent
debris from entering the instrument and drain and dry the CPC before
shipping.
C a u t i o n
With the vacuum on and butanol in the reservoir, do not tip the counter
more than 10° in any direction. It is recommended to turn off the CPC
and disconnect the butanol fill bottle before the CPC is being moved or
tilted for longer than a few seconds to prevent flooding the sensor.
