35
CHAPTER 7
Workflows
Workflows step you through the measurement process and assist in
calculating and logging the measurement points.
The following workflows are available:
Percent Outside Air (%OA) (9600, 9630, 9650, 9650-NB)
Heat Flow (9650, 9650-NB with 964 or 966 probe)
Duct Traverse (9650, 9650-NB)
Displayed workflows are dependent on instrument model and
attached probe. Percent Outside air will be shown if a probe that
measures air temperature or CO
2
is connected. Heat Flow will be
shown on the 9650 or 9650-NB if a 964 or 966 probe is attached.
Duct traverse will be shown on the 9650 or 9650-NB and is used
with the differential pressure sensor or a connected probe that
measures air velocity.
Perc en t Outsid e Air (%O A) Calculat ion
Procedu re
After selecting Workflows from the
Main Menu, select % Outside Air
to view the % Outside Air screen.
