TurboChef HIGH H BATCH 2 User Manual

Optional I
nstalla
tion Items
Oven Restraint Kit (P/N: TC3-0242 KIT)
The o
ven restraint kit is an optional device that
prevents the oven from moving forward during use
and cleaning. I
t will not prevent the oven from
falling off a countertop if the oven is pulled off or
the legs are allowed to slide off the edge. Call
1-800-90TURBO or your Authorized Distributor
for more information.
O
ven Cart
Construction
o
Available heights: 18′′ (457 mm) or
24′′ (610 mm)
o
304 stainless steel
o
14-gauge 304 stainless steel top
o
16-gauge 304 solid stainless steel shelf
o
F
our
6
′
′
(152 mm) high polyur
ethane tir
ed
casters, fr
ont two with safety locking brakes;
bolt-on to stainless steel leg
S
tandard Features
o
R
einfor
cement: Welded gusset plates between
legs and top to ensure rigidity/eliminate stand
racking
o
F
rame: Fully welded 1.5
′′ x 1.5′′ (38 mm x 38
mm) squar
e stainless steel tube
o
Easy to assemble
Call 1-800-90TURBO or your Authorized
D
istributor for more information.
18′′ (457 mm) Oven Cart Dimensions
Height 18′′ (457 mm)
with single o
v
en
39.4
′′ (1001 mm)
with stacked o
v
ens*
top unit without legs
56.8
′′ (1443 mm)
top unit with legs
60.8
′′ (1544 mm)
Width 27.8′′ (706 mm)
with single oven 27.8′′ (706 mm)
with stacked ovens* 27.8′′ (706 mm)
D
epth
26.625
′′ (676 mm)
with single o
v
en 31.7
′′ (805 mm)
with stacked ovens* 31.7′′ (805 mm)
24′′ (610 mm) Oven Cart Dimensions
H
eight 24
′′ (610 mm)
with single oven 45.4′′ (1153 mm)
with stacked ovens*
top unit without legs 62.8′′ (1595 mm)
top unit with legs 66.8′′ (1697 mm)
W
idth 27.8
′′ (706 mm)
with single oven 27.8′′ (706 mm)
with stacked ovens* 27.8′′ (706 mm)
Depth 26.625′′ (676 mm)
with single oven 31.7′′ (805 mm)
with stacked o
v
ens* 31.7
′′ (805 mm)
*R
equir
es Stacking Bracket.
Assembly instr
uctions are included with the cart.
I
f additional help is needed, call 1-800-90TURBO
or y
our Authorized Distributor.
FIGURE 6: 24′′ (610 mm) Oven Cart with Oven(s)
7
SPECIFICATIONS AND INSTALLATION
NO
TE: I
f using 18”
(457 mm) car
t, subtract
6” (152 mm) fr
om all
measurements.
