Setting
Setting and visualizing with the Turck Radar Monitor
22
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
9.2 Setting via IO-Link
The device can be parameterized within the technical specifications (see data sheet) via the IO-
Link communication interface – both offline, e.g. with the configuration tool as well as also on-
line via the controller. An overview of the different functions and properties that can be set and
used for IO-Link or SIO mode can be found in the chapter “Setting” and in the IO-Link para-
meter manual of the device. Detailed instructions on the parameterization of devices via the IO-
Link interface are provided in the IO-Link commissioning manual.
All the parameters can be changed in IO-Link mode via the controller during commissioning as
well as during operation. In SIO mode the device operates according to the last setting made in
IO-Link mode.
9.3 Setting and visualizing with the Turck Radar Monitor
The device can be parameterized and tested via a Turck IO-Link master (e.g. TBEN-S2-4IOL). The
integrated web server of the IO-Link master offers access to all the parameters of the sensor
IODD. An overview of the IO-Link parameters as well as descriptions are provided in the IO-Link
parameter manual. The Turck Radar Monitor is also available for visualizing process data.
Access to the sensor parameters and the Turck Radar Monitor requires the connection of a
Turck IO-Link master. The following table shows the firmware status of the IO-Link masters re-
quired for using the Turck Radar Monitor:
IO-Link master Firmware status
FEN20-4IOL V1.2.0.0
TBEN-L4/5-8IOL V3.3.2.0
TBEN-LL-8IOL V1.1.1.0
TBEN-S2-4IOL V3.4.1.0
Refer to the instructions for use of the relevant device for information on the Turck IO-Link mas-
ters.
Connect the IO-Link master to the power supply.
Connect the IO-Link master to a PC via the Ethernet interface.
Connect the radar sensor to an IO-Link port of the IO-Link master.
